Detailaufnahme S 3a cliq
Key
1 Hanger no. 12/.../...
2 Main tee cliq-24-MR, every 100 mm or 156.25 mm slotted
3 Cross tee short, cliq-24-CT, length: 600 mm or 625 mm
4 Cross tee long, cliq-24-CT, length: 1200 mm or 1250 mm
5 Cross tee, short, cliq-24-CT, length: 300 mm, 312.5 mm or 400 mm
6 Shadow wall angle no. 50/ 15G
7 Contura block no. 42/24
8 Axis distance

Source: DS 9991

Technical data

Dimensions

Dimensions: 600 x 600 mm, 625 x 625 mm, 1200 x 600 mm, 1250 x 625 mm
Widths: 300 mm, 312.5 mm, 400 mm
Lengths: 1200 mm, 1250mm*

(See OWAlifetime collection price list for minimum quantities and surcharges.)

Edges

6

Tile thickness

Approx. 15 mm and 20 mm (OWAcoustic premium)
(Also suitable for OWAcoustic smart)

Fire behaviour

A2-s1,d0 as per EN 13501-1

Resistance to fire
Metal system

All metal components are galvanized or white coated. For further details and colours see
OWAlifetime collection price list

Minimum suspension depth

75 – 100 mm (depending on the existing ceiling slab) for easy removal of the 120 mm tiles.
